The ‌IBDG-90KVA transformer‌ is a high-power industrial welding transformer designed for ‌spot welders and butt-welders‌, featuring ‌90KVA rated power, 2-phase 825V input, and 7-step voltage output (0-578V)‌. With ‌F-class insulation, 3800V withstand voltage‌ (≤0.5mA leakage), and a ‌1-year warranty‌, it ensures reliable performance in demanding welding applications.

The ‌IBDG-80KVA transformer‌ is a high-power (80KVA, 3000J) industrial welding power supply designed for ‌spot welding machines‌, featuring ‌380V input, 13V output, F-class insulation, and 3800V withstand voltage‌ (≤0.5mA leakage). It supports ‌50-60Hz‌ frequency with ‌50% duty cycle‌, ensuring stable performance in demanding welding applications.

The ‌IBDG-63KVA‌ transformer is a high-performance medium-frequency (50-80Hz) power supply unit designed for industrial welding applications, delivering ‌63kVA‌ rated power with ‌380V input‌ and adjustable output levels for spot welders and butt-welders. It features ‌F-class insulation, 3800V withstand voltage‌ (1 min, ≤0.5mA leakage current), and ‌temperature protection (85℃)‌, ensuring durability in demanding environments.

The IBDG-60KVA is a medium-frequency transformer designed for resistance and butt welding machines. Suitable for 50Hz-60Hz power grid environments, it supports a variety of output voltages (0-100V-130V-160V), has a high insulation grade (F-class) and a strong voltage withstand capability (3800V/1min).

The IBDG-40KVA medium-frequency welding transformer is specifically designed for spot and butt welding. It utilizes a high-efficiency magnetic circuit and high-temperature-resistant windings, ensuring stable output under industrial loads. Optimized core laminations reduce no-load losses, and forced air cooling supports operation in ambient temperatures ranging from -25°C to +55°C, meeting the stringent welding consistency and equipment life requirements of the automotive and metalworking industries.

The IBDG-5KVA is a medium-frequency welding transformer designed specifically for resistance welding machines (spot and butt welders). It features a 3KVA rated power, a 50Hz-60Hz wide-band input, a 1.5V low-voltage output, and Class F insulation. It also provides ±85°C temperature control and a 3800V withstand voltage test, making it suitable for industrial welding scenarios.

The IBDG-3KVA is a low-voltage, high-current industrial transformer designed specifically for spot and butt welders. It features a rated power of 3KVA, a 220V/50-60Hz input, and a 1.5V output. It offers Class F insulation protection and 85°C temperature control, making it suitable for high-precision welding applications.

The IBZPZDPS-250KVA is an industrial-grade medium-frequency transformer designed specifically for water-cooled welding equipment. Rated at 250KVA, it supports a 500V input voltage at 50-60Hz and delivers a stable 12.6V DC output. It features Class F insulation protection and intelligent temperature control, making it suitable for high-load applications such as plasma cutting and argon arc welding.

IBZPZDPS-125KVA is a water-cooled medium-frequency transformer designed specifically for welding equipment. It has an input voltage of 500V (50Hz-60Hz), an output of DC10V, a rated power of 125KVA, and is equipped with intelligent temperature control and a water cooling circulation system (8L/min).

The IBZPZDPS-100KVA industrial-grade water-cooled transformer is designed specifically for high-stability welding power supplies. It features a 50Hz-60Hz broadband input adapter, a built-in 85℃ precision temperature control module, and an 8L/min high-efficiency water-cooling circulation system. It also passes Class F insulation certification, ensuring reliable operation in harsh operating conditions.

The IBZPZDPS-75KVA is a 75kVA transformer designed for water-cooled welding machines. It features a 500V input voltage and an 8.8V DC output. It utilizes Class F insulation and features temperature control protection (85℃), circulating water cooling (8L/min), and withstand voltage testing (3800V/1min, leakage current ≤0.5mA), making it suitable for a variety of water-cooled welding equipment.

The ACIBZPZDPS-250KVA is a 250KVA medium-frequency water-cooled transformer designed specifically for 1000Hz medium-frequency welding equipment. It offers a 500V input and AC15V output, Class F insulation, a 3800V withstand voltage, and intelligent temperature control (85°C), making it compatible with various water-cooled welding machines.
