Single Phase Pad Mounted Transformer

Product Introduction

The single-phase box transformer is designed to significantly improve the performance of its kVA rating, mainly in terms of compact size, lighter weight, safety and sustainability. A significant advantage of this equipment is that it does not require a distribution room and can be flexibly placed directly indoors or outdoors, or even on streets and green spaces, which can effectively ensure personal safety while taking into account the function of power supply facilities and adding beauty to the surrounding environment.

Single-phase box transformers are widely used in various places, including residential areas, commercial centers, stations, airports, factories, enterprises, hospitals and schools. This type of equipment is small in size and is particularly suitable for outdoor installation. It does not require an additional protective shell, which greatly simplifies the installation and maintenance process. Single-phase box transformers also comply with international standards such as IEC60076, ANSI/IEEE C57.12.00, C57.12.20, C57.12.38, C57.12.90, etc., ensuring that it meets industry requirements in terms of performance and safety.

By adopting advanced materials and technologies, the single-phase box-type transformer not only improves energy efficiency, but also reduces the impact on the environment, reflecting the concept of sustainable development. Its flexible installation method and versatility make it an indispensable and important part of the modern power system, which can meet the growing power demand and provide users with safe and reliable power supply.

Standard Features

●Quality System ISO 9001 certified

●Meet or exceeds ANSIMEEE and NEMA standards

●Tank coating exceeds IEEE Std C57.12.28"-2005 and IEEE Std C57.12.29-2005standards (stainless steel units only)

●Full compliance with IEEE Std C57.12.28"-2005standard enclosure integrity requirements

●Automatic pressure relief device

●Fluid fill and drain provisions

●Laser engraved nameplate

●Floating lock pocket for easy alignment

●Decal bushing designations

●Welded domed tank cover

●Tamper strips of noncorrosive material

●Crowned tank

●Removable sill

●Recessed stainless steel lifting provisions

●Hinged door with stainless steel hinge pins and barrels

●Ground strap from X2 to tank ground

●HV bushing wells for dead front elbow connectors

Technical Data Sheet

Technical Data for Single Phase Pad Mounted Distributation Transformer

Note: The above data is only subject to our standard design, special requirement can be customized.
