ABILKEEN MV Instrument Transformers - JDZ10/JDZX10 Series for Metering & Protection
The JDZ10-3, 6, 10 (A1, A2, B) and JDZX10-3, 6, 10 (A1G, A2G, BG) transformers are designed as single-phase, double-wind transformers through combination of advanced epoxy resin cast technology. JDZ10-3, 6 and 10 are fully insulated and constructed of semi-sealed (or unsealed) material specifically for use in a 50Hz or 60Hz electrical system.
One of the most critical aspects of high-voltage environments is dielectric strength, and the cast resin insulation used in ABILKEEN series products provides superior moisture, pollution and contaminant protection to ensure long-term dependability even in extremely demanding industrial conditions. The insulation rated levels precisely match the system voltage levels and are available in configurations of 3.6/25/40 kV for the 3kV transformers and up to 12/42/75 kV for the 10kV transformers, thereby enabling them to endure daily operation and transient overvoltages.
The other outstanding feature of the ABILKEEN JDZ10 and JDZX10 transformer families is that they maintain metering-class accuracy through a wide range of load options. The JDZ10 is designed to offer exceptionally high accuracy class performance (0.2, 0.5) for revenue metering and grid monitoring so that every kilowatt hour of energy is accounted for with complete accuracy.
For protection applications, the JDZX10 series (which include a residual voltage winding for determining ground fault) provide the reliability necessary for relay protection applications. The rated output ranges from 15 VA to 90 VA depending on the accuracy rating, model (A or B), thermal rating and burden capacity; therefore, these transformers deliver the thermal endurance and burden capacity needed for repeatable performance and protection of critical assets in generation and distribution networks.
Adaptability in Design and Use
ABILKEEN recognizes that today's electrical equipment needs to be compact and adaptable for use. The JDZ10/JDZX10 series are made with an upright design that is small in area and light-weight in construction which allows for installation in any angle. Such adaptability is important in tight spaces found in metal-boxed switchgear or compact substations.
An equally important benefit of the design is the ease of integration. The secondary outlets are in a terminal box designed for multi-directional wiring. This will greatly help simplify wiring and increase anti-theft security for end-users of the device. The JB10/JBZX10 series have critical data transmission between high voltage primary and intelligent electronic devices (IEDs) to monitor the electric grid in industrial automation through precise motor control or renewable energy systems with solar and wind generation.
Why Choose ABILKEEN for Medium Voltage?When specifying components used with 3kV to 10kV systems, the manufacturer can significantly affect the future health of the system. ABILKEEN products are manufactured per International Standards such as GB1207 to ensure they meet high performance and safety standards. The JDZ10 or JDZX10 series are the best products to invest in for your system. Highly-Quality Materials: Using high permeability (insulated) steel cores and copper windings, and manufacturing them with high-quality materials and energy conversion components that utilize strict thermal management during their manufacture. Proven Reliability: Designed to withstand normal environmental conditions of negative five degrees celsius (5o C) to positive forty degrees Celsius (40oC) and altitudes of 1000 metres over 24 hours – these designs are truly robust. Trust in ABILKEEN's commitment to Best Price & Best Quality in China, and the additional assurance of either CE or ISO certification, which guarantees that all transformers manufactured by ABILKEEN deliver an accurate and long-lasting performance. Conclusion The JDZ10 and JDZX10 series of transforms represents the very best of medium voltage instrument transformer technology. With the capability to precisely measure electrical current along with a high strength epoxy insulation (for long-lasting durability) and an Engineer oriented design, these transformers are the best solution for Engineers focused on improving the safety, efficiency, and reliability of their electrical networks. For your next upgrade/installation of a substation, switchgear, or industrial site, choose ABILKEEN to provide the highest quality transformers to fit your needs.
